--- title: How do I factor Predominant Wind Into my Data Center Site? description: factor in predominant wind direction with wind rose --- [Skip to content](https://support.testfit.io/knowledge/how-do-i-factor-predominant-wind-into-my-data-center-site#main-content) [![](https://support.testfit.io/hs-fs/hubfs/primary%20wordmark.png?width=150&height=113&name=primary%20wordmark.png)](https://testfit.io/?hsLang=en) Open main navigation Close main navigation - - [Contact us](https://support.testfit.io/knowledge/kb-tickets/new) [Contact us](https://support.testfit.io/knowledge/kb-tickets/new?hsLang=en) Welcome to the TestFit Knowledge Base - There are no suggestions because the search field is empty. 1. [TestFit Knowledge Base](https://support.testfit.io/knowledge?hsLang=en) 2. [Site Development](https://support.testfit.io/knowledge/site-development?hsLang=en) 3. [Datacenters](https://support.testfit.io/knowledge/site-development?hsLang=en#datacenters) February 9, 2026 # How do I factor Predominant Wind Into my Data Center Site? ## Wind Rose allows you to align the yards of your Data Center Sites to a predominant wind direction Should you need to align your data center yards to a specific wind direction follow these steps: ![](https://support.testfit.io/hs-fs/hubfs/image-png-Dec-09-2025-03-16-31-0364-PM.png?width=613&height=518&name=image-png-Dec-09-2025-03-16-31-0364-PM.png) 1. With the Data Center layer selected, click the ***Draw*** button associated to the *Row axis ![](https://support.testfit.io/hs-fs/hubfs/image-png-Dec-09-2025-03-18-51-0748-PM.png?width=347&height=599&name=image-png-Dec-09-2025-03-18-51-0748-PM.png)* 2. Either: 1. Hover your mouse over the wind rose compass in the botton right corner of the canvas area and click when the yards are aligned as you desire. ![wr1](https://support.testfit.io/hs-fs/hubfs/wr1.gif?width=670&height=377&name=wr1.gif) 2. Click anywhere in Canvas and draw the desired alignment of the datacenter/yards. ![wr2](https://support.testfit.io/hs-fs/hubfs/wr2.gif?width=670&height=377&name=wr2.gif) --- ### Information Resources - Wind Rose data is provided by the NASA POWER (Prediction of Worldwide Energy Resources) API. - Information is based on 15 year historical average of predominant wind direction. **Source Website: [https://power.larc.nasa.gov/](https://power.larc.nasa.gov/)** - [Getting Started](https://support.testfit.io/knowledge/getting-started?hsLang=en#main-content) - [Interface](https://support.testfit.io/knowledge/getting-started?hsLang=en#interface) - [Setting up a Deal](https://support.testfit.io/knowledge/getting-started?hsLang=en#setting-up-a-deal) - [Site Design & Configuration](https://support.testfit.io/knowledge/getting-started?hsLang=en#site-design-configuration) - [Fundamentals](https://support.testfit.io/knowledge/fundamentals?hsLang=en#main-content) - [Regions](https://support.testfit.io/knowledge/fundamentals?hsLang=en#regions) - [Key Functions](https://support.testfit.io/knowledge/fundamentals?hsLang=en#key-functions) - [Roads](https://support.testfit.io/knowledge/fundamentals?hsLang=en#roads) - [Site Development](https://support.testfit.io/knowledge/site-development?hsLang=en#main-content) - [Mass-Based](https://support.testfit.io/knowledge/site-development?hsLang=en#mass-based) - [Housing - High Density & Gurban](https://support.testfit.io/knowledge/site-development?hsLang=en#housing-high-density-gurban) - [Housing - Low Density & Subdivision](https://support.testfit.io/knowledge/site-development?hsLang=en#housing-low-density-subdivision) - [Housing - Garden](https://support.testfit.io/knowledge/site-development?hsLang=en#housing-garden) - [Industrial](https://support.testfit.io/knowledge/site-development?hsLang=en#industrial) - [Datacenters](https://support.testfit.io/knowledge/site-development?hsLang=en#datacenters) - [Generative Design](https://support.testfit.io/knowledge/site-development?hsLang=en#generative-design) - [Parking](https://support.testfit.io/knowledge/site-development?hsLang=en#parking) - [Retail](https://support.testfit.io/knowledge/site-development?hsLang=en#retail) - [Core-Based](https://support.testfit.io/knowledge/site-development?hsLang=en#core-based) - [Web App](https://support.testfit.io/knowledge/web-app?hsLang=en#main-content) - [Deal Pipeline & Asset Management](https://support.testfit.io/knowledge/web-app?hsLang=en#deal-pipeline-asset-management) - [Deal Actions & Edits](https://support.testfit.io/knowledge/web-app?hsLang=en#deal-actions-edits) - [Reports](https://support.testfit.io/knowledge/web-app?hsLang=en#reports) - [Quantities & Costs](https://support.testfit.io/knowledge/web-app?hsLang=en#quantities-costs) - [Pro Forma](https://support.testfit.io/knowledge/web-app?hsLang=en#pro-forma) - [MCP](https://support.testfit.io/knowledge/mcp?hsLang=en) - [Reports & Exporting](https://support.testfit.io/knowledge/reports-exporting?hsLang=en#main-content) - [PDF Exports](https://support.testfit.io/knowledge/reports-exporting?hsLang=en#pdf-exports) - [SketchUp Export](https://support.testfit.io/knowledge/reports-exporting?hsLang=en#sketchup-export) - [TestFit to Revit](https://support.testfit.io/knowledge/reports-exporting?hsLang=en#testfit-to-revit) - [Account Management](https://support.testfit.io/knowledge/account-management?hsLang=en#main-content) - [Administration](https://support.testfit.io/knowledge/account-management?hsLang=en#administration) - [Account](https://support.testfit.io/knowledge/account-management?hsLang=en#account) - [Latest Release](https://support.testfit.io/knowledge/latest-release?hsLang=en#main-content) - [2026](https://support.testfit.io/knowledge/latest-release?hsLang=en#2026) - [2025](https://support.testfit.io/knowledge/latest-release?hsLang=en#2025) - [2024](https://support.testfit.io/knowledge/latest-release?hsLang=en#2024) - [2023](https://support.testfit.io/knowledge/latest-release?hsLang=en#2023) - [2022](https://support.testfit.io/knowledge/latest-release?hsLang=en#2022) - [Beta](https://support.testfit.io/knowledge/latest-release?hsLang=en#beta) - [FAQ](https://support.testfit.io/knowledge/faq?hsLang=en) - [Troubleshooting](https://support.testfit.io/knowledge/troubleshooting?hsLang=en#main-content) - [Issues](https://support.testfit.io/knowledge/troubleshooting?hsLang=en#issues) - [Errors](https://support.testfit.io/knowledge/troubleshooting?hsLang=en#errors) [![Chill listening crop-3](https://support.testfit.io/hs-fs/hubfs/primary%20wordmark.png?width=124&height=40&name=primary%20wordmark.png "Chill listening crop-3")](http://testfit.io?hsLang=en) Copyright © 2025, TestFit
